Pig traps

Overview

‍

Pig trap operations involves the launching and receiving pipeline pigs, it’s amongst the most sequentially complex and potentially hazardous procedures within the oil and gas and petrochemical industries.

‍

A pig trap interlock sequence can involve dozens of valves that must be operated in a precise order, with each step verified before the next can proceed. Any deviation from the correct sequence risks catastrophic consequences: uncontrolled product release, high-pressure exposure, environmental contamination and serious injury.

‍

‍

The challenge

‍

Pig trap procedures typically involve multiple isolation valves, drain valves, vent valves, bypass valves and the closure door itself. Written procedures alone cannot guarantee correct execution, human error, time pressure, shift changes and unfamiliarity with equipment all contribute to procedural failures.

‍

The Alcatraz solution

‍

Alcatraz provides a complete interlocking solution for pig trap operations, combining mechanical valve interlocks (QL-Range and ML-Range), closure door locks, MOV locks, optional PILOT digital oversight and our ECO-Drive range.

‍

Every valve in the sequence is interlocked using coded keys or using our digital keyless interlocks, that enforce the correct operating order.

‍

The closure door cannot be opened until all isolation and depressurisation steps have been completed and verified.

‍

‍

Key benefits

‍

•   Enforced sequential valve operation,  no step can be skipped

•   Closure door protection, physically locked until safe conditions are met

•   Complete audit trail with PILOT digital integration

•   Elimination of human error from safety-critical sequences

•   Compliance with industry standards and operating procedures

•   Eco-Drive for large / high rotation valves

‍

‍

Products used

‍

QL-Range quarter-turn interlocks, ML-Range multi-turn interlocks, Closure Door Locks, MOV Locks, PILOT digital oversight, ARVC remote manual valve actuation & Eco-Drive range.

‍
