Helix Cable Drive
The Helix cable driven ARVC is the standard configuration for remote manual valve actuation. Rotary input is applied to the input shaft at the operator station, and torque is transmitted through a cable drive gear which drives the helixcable in linear motion which then rotates the output shaft at the valve station actuator.
The Operator & Host drive station are compact and mounted with bespoke mounting kits. Thesystem requires no external power source at the valve location.
Product datasheets, installation manuals, and certification documents are available for download via OneHub or below. Please provide your email to access the downloads.
- Helix cable for reliable long distance torque transmission
- No electrical power supply required at the valve
- Bespoke mounting kits for Operator & Host Valve, for secure connection
- Suitable for both quarter-turn and multi-turn valves
- Can be fully integrated with Alcatraz interlocking sequences
- Ideal for long-distance remote actuation
Marine, offshore, nuclear, chemical and petrochemical facilities, confined spaces and elevated process areas.
